HZS50 series concrete batching plant(concrete mixing plant) belongs to compulsory and efficiency equipment, which can produce various kinds of concrete including quaking concrete and hard concrete.
1.It is widely used on small and medium scale building project, road and bridge projects . It’s also an ideal equipment to produce commercial concrete.
2. The main mixer of this series concrete batching plant use JS series twin-shaft concrete mixer which is very reliable.
3. It can be operated and maintained conveniently through high technology control system with the newest design concept.
4.Saving space
| Specification | Unit | Value |
|---|---|---|
| Productivity | m3/h | 50 |
|
Capacity of Mixer |
m3 | 1 |
|
Discharge Height |
m | 3.8 |
|
Aggregate Bin |
Quantity | 3 |
|
Capacity of Aggregate Bin |
m3 | 10 |
|
Max. Weighing Value of aggregate |
kg | 3000 |
|
Max. Weighing Value of cement |
kg | 600 |
|
Max. Weighing Value of water |
kg | 400 |
|
Max. Weighing Value of additive |
kg | 50 |
| Feeding Type | / | Skip Hopper |
| Cement Silo | / | Optional |
| Cement Screw Conveyor | / | Optional |
| Control Mode | / | Auto/Semi control |
